Hydraulic cylinder seal kits are used to seal the gap between different parts of the hydraulic cylinder. The function of hydraulic cylinder seal kits is to prevent oil leakage, to assure the working pressure of the hydraulic system, to maintain its power.
Boom Cylinder seal kit is, as the name suggests, fitted into the boom cylinder.
There are regularly three cylinders for the excavator, boom cylinder, arm cylinder, bucket cylinder.
Arm cylinder is the top one, and it's usually be called as top cylinder;
The bucket cylinder is the one that connects and controls the bucket.
Boom cylinder is the one (or the two) near the cabin. Usually, there is one piece boom cylinder for the small excavator under 10-tun; the bigger excavator's two pieces boom cylinders. But there is an exception too when the driver will remove one piece for a special purpose, say at some particular working place, it is convenient to work by one cylinder. Soft remind: all refit job should be operated by an experienced technician.

When you open and repair the cylinder, please follow below operation:

1. Take off the cylinder from the machine.

2. Remove the head assembly and the rod assembly from the stick cylinder group.

3.If it always happens that the seal kit not perform well soon after it fitted, there maybe problem of the cylinder assembly itself. It is better to check the cylinder assembly whether need to change it.

4.Meansure the seal kits before fitting.

5.Install the seals.

After fix the cylinder assy, test it first before reinstall the stick culinder group on the machine.

Part No

Parts name

Part No

Parts name

707-02-X7170

CYLINDER GROUP,L.H. (FINAL COATING)

17M-63-X1011

CYLINDER GROUP,L.H.

707-02-X7180

CYLINDER GROUP,R.H. (FINAL COATING)

17M-63-X1021

CYLINDER GROUP,R.H.

17M-63-01011

CYLINDER ASS'Y

17M-63-12141

CYLINDER

175-63-22150

BUSHING

707-29-13760

HEAD,CYLINDER

07177-08040

BUSHING

707-51-80211

PACKING,ROD

195-63-92190

SEAL,DUST

07179-13094

RING,SNAP

07000-12125

O-RING OEM

07146-02126

RING,BACK-UP

07000-02130

O-RING OEM

17M-63-12120

ROD,PISTON

707-66-80040

CAP OEM

175-63-22241

SHIM, 1.0MM

01011-52025

BOLT

01643-32060

WASHER

17M-63-12131

PISTON ASS'Y

07000-12060

O-RING

707-35-52900

RING,BACK-UP

707-44-13180

RING,PISTON

707-39-13110

RING,WEAR

707-40-13051

RETAINER

707-40-13170

SPACER

707-83-10073

VALVE

01252-31235

BOLT

175-63-22160

HOOK

01010-51665

BOLT

01643-31645

WASHER

17M-63-14100

VALVE ASS'Y,QUICK DROP

195-63-14180

SPRING

01642-21216

WASHER

195-63-14162

COLLAR

07000-12055

O-RING

01011-51615

BOLT

17M-63-12270

TUBE,L.H.

17M-63-12170

TUBE,R.H.

07000-13035

O-RING

01010-51055

BOLT

01010-51060

BOLT

01643-31032

WASHER

195-63-14130

ELBOW

07000-13045

O-RING

01010-51270

BOLT

01010-51280

BOLT

01643-31232

WASHER

07000-13048

O-RING

01010-51065

BOLT

01010-51075

BOLT

17M-61-22660

TUBE,L.H.

17M-61-22670

TUBE,R.H.

07000-13038

O-RING

01010-51260

BOLT

07282-03411

CLAMP

01010-51020

BOLT

707-88-14460

PLATE

01010-51025

BOLT

07283-23442

CLIP

01599-01011

NUT

707-98-45620

SERVICE KIT
