| Product: | 706-73-01181KT 706-73-01181 Swing Motor Seal Kit | Part Number: | 706-73-01181KT 706-73-01181 7067301181KT 7067301181 |
|---|---|---|---|
| Fit For Model: | Komatsu PC120-6 PC128US PC138US PC130-7 | Group: | Swing Motor Seal Kit / Hydraulic Motor Seal Kit |
| Loading Port: | HUAGNPU,China (Mainland) | Packing: | Neutral Packing / HQPA Packing |
| High Light: | 706-73-01181,PC130-7 Swing Motor Seal Kit,PC120-6 Swing Motor Seal Kit |
||
|
Swing motors are hydraulic motors that form the proper turning force of excavator booms using oil pressure, shift rotation either to the right or left and convey or cut off turning power. Swing motor seal kits maintain the power of the swing motor. If the swing motor leaks oil, the boom cylinder will be powerless. |
2.General Product Information:
| Brand Name | HQPA/OEM |
| Product Name | 706-73-01181KT 706-73-01181 Swing Motor Seal Kit for Komatsu PC120-6 PC128US PC138US PC130-7 |
| Product style | Swing Motor Seal Kit / Motor Seal Kit |
| Part No. | 706-73-01181KT 706-73-01181 7067301181KT 7067301181 |
| Related parts: | Boom Cylinder Seal Kit / Arm Cylinder Seal Kit / Swing Motor Seal Kit / Travel Motor Seal Kit / Main Pump Seal Kit / Pilot Pump Seal Kit / Regulator Valve Seal Kit / Main Control Valve Seal Kit |
| Appliion | Komatsu PC100L-6 PC100-6 PC100-6E PC100-6S PC120-6H PC120-6E PC120-6Z-A1 PC120-6Z PC120-6 PC128US-1 PC120SC-6 PC120LC-6E0 PC120LC-6 PC120-6E0-T2 PC120-6E0 PC120-6S PC120-6J PC130-6 PC130-6E0-T2 PC130-6G PC130-6E PC130-7 PC130-7K PC150LGP-6K PW148-8 PW140-7 PW148-10 PW148-11 |
| MOQ | 1 PC |
| Condition | 100% New |
| Package | Inner-Plastic Bag; Outer -Standard Carton Box. |
| Payment | Western Union, L/C, T/T, MoneyGram, D/A, D/P etc. |
| Departure ports | Huangpu(Guangzhou), China (Mainland) |
| Delivery time | 3-5 days after payment received(public holiday excluded) |
| Place of origin | China (Mainland) |
| Appliion | Excavators, heavy machinery, mining, earth-moving, construction machinery, digger, car, truck. |
3. Fit Model
|
Part Number: 706-73-01181KT 706-73-01181 |
4.Related parts
| Part No | Parts name | Part No | Parts name |
| 203-26-00123 | SWING MACHINERY A. | 706-73-01181 | MOTOR ASS'Y |
| 201-26-62190 | RING | 07042-30108 | PLUG |
| 01011-81230 | BOLT | 01643-31232 | WASHER |
| 07049-01215 | PLUG | 203-26-61480 | GAUGE |
| 203-26-61470 | FILLER | 01010-81655 | BOLT |
| 01643-31645 | WASHER | 04020-01638 | PIN |
| 07049-02025 | PLUG | 706-73-01181 | MOTOR ASS'Y |
| 706-73-43110 | CHN,MOTOR | 706-73-00020 | HOUSING SUB ASS'Y |
| 706-73-40010 | BEARING | 706-73-42820 | PIN |
| 706-73-72680 | PLUG | 07002-11223 | O-RING |
| 709-25-11650 | VALVE,CHECK | 709-25-11361 | SPRING |
| 709-25-11640 | PLUG | 07000-12020 | O-RING |
| 706-73-72420 | VALVE | 706-73-72440 | SPRING |
| 706-73-72430 | PLUG | 07002-12434 | O-RING |
| 07000-02145 | O-RING | 01252-61240 | BOLT |
| 706-73-43960 | SHAFT,DRIVE | 706-73-43880 | BEARING |
| 706-73-43810 | SPACER | 706-73-43610 | SPRING |
| 706-73-43620 | SEAT | 706-73-43890 | BEARING |
| 706-73-05030 | SPACER KIT | 04064-03515 | RING,SNAP |
| 708-7T-12230 | SEAL,OIL | 04065-04518 | RING,SNAP |
| 706-73-43190 | BLOCK,CYLINDER | 706-73-43742 | PLATE,VALVE |
| 720-68-19610 | PIN | 706-73-43120 | SHAFT,CENTER |
| 706-73-43130 | RING,CENTER | 706-73-41110 | SPRING |
| 706-73-05020 | RETAINER KIT | 706-73-43160 | PISTON SUB ASS'Y |
| 706-73-92340 | PLATE | 706-73-92350 | DISK |
| 706-73-92380 | PISTON,BRAKE | 706-73-92390 | RING,BRAKE |
| 07000-12115 | O-RING | 07000-12130 | O-RING |
| 708-7T-15150 | SPRING | 702-73-01520 | VALVE ASS'Y,RELIEF |
| 723-60-22230 | RING,BACK-UP | 07000-F2016 | O-RING |
| 07002-12434 | O-RING | 706-77-72280 | PLUG |
| 07002-12034 | O-RING | 702-15-73000 | VALVE ASS'Y |
| 07000-03042 | O-RING | 07000-11007 | O-RING |
| 01252-60825 | BOLT |
