Product Details:
Payment & Shipping Terms:
|
| Product: | 708-2H-00450 708-2H-00022 Hydraulic Main Pump Seal Kit | Part Number: | 708-2H-00450KT 708-2H-00022KT 708-2H-00450 708-2H-00022 7082H00450KT 7082H00022KT 7082H00450 7082H00022 Hydraulic Pump Assy |
|---|---|---|---|
| Fit For Model: | Komatsu PC300-7-AA PC300LC-7 PC300LC-7-BA PC300-7 PC350LC-7 | Group: | Hydraulic Main Pump Seal Kit / Pump Seal Kit |
| Loading Port: | HUAGNPU,China (Mainland) | Packing: | Neutral Packing / HQPA Packing |
| High Light: | 708-2H-00450,708-2H-00022 Main Pump Seal Kit,PC350-7 Main Pump Seal Kit |
||
|
The hydraulic main pump is a kind of fluid pump. About the fluid sealing, it usually uses the mechanical seal to contain the fluid within a vessel (typically pumps, mixers, etc.) where a rotating shaft passes through a stationary housing or occasionally, where the housing rotates around the shaft.
Mechanical seals are usually fixed at the point of entry or exit of a rotating shaft. Typically it is used to prevent the leakage of one high-pressure fluid into a lower pressure fluid. |
2.General Product Information:
| Brand Name | HQPA/OEM |
| Product Name | 708-2H-00450 708-2H-00022 Hydraulic Main Pump Seal Kit for Komatsu PC350-7 |
| Product style | Hydraulic Main Pump Seal Kit / Main Pump Seal Kit |
| Part No. | 708-2H-00450KT 708-2H-00022KT 708-2H-00450 708-2H-00022 7082H00450KT 7082H00022KT 7082H00450 7082H00022 Hydraulic Pump Assy |
| Related parts: | Boom Cylinder Seal Kit / Arm Cylinder Seal Kit / Swing Motor Seal Kit / Travel Motor Seal Kit / Main Pump Seal Kit / Pilot Pump Seal Kit / Regulator Valve Seal Kit / Main Control Valve Seal Kit |
| Appliion | Komatsu PC300-7-AA PC300LC-7 PC300LC-7-BA PC300-7 PC350LC-7 PC350-7-AA PC350LC-7-BA PC350-7 |
| MOQ | 1 PC |
| Condition | 100% New |
| Package | Inner-Plastic Bag; Outer -Standard Carton Box. |
| Payment | Western Union, L/C, T/T, MoneyGram, D/A, D/P etc. |
| Departure ports | Huangpu(Guangzhou), China (Mainland) |
| Delivery time | 3-5 days after payment received(public holiday excluded) |
| Place of origin | China (Mainland) |
| Appliion | Excavators, heavy machinery, mining, earth-moving, construction machinery, digger, car, truck. |
3. Fit Model
|
Part Number: 708-2H-00450 708-2H-00022 |
4.Related parts
| Part No | Parts name | Part No | Parts name |
| 708-2H-00022 | Pump Assembly | 708-2H-01450 | Pump Subassembly |
| 708-2H-04670 | CHN Assembly,Front | 708-8E-16150 | Plug |
| 07002-61023 | O-ring | 07000-B2012 | O-ring |
| 04530-11222 | Bolt, Eye | 07044-12412 | Plug |
| 07002-62434 | O-ring | 07040-12414 | Plug |
| 708-2H-21860 | Plate | 708-2H-04850 | Gear Kit |
| 708-2H-32311 | Gear, Bevel | 708-2H-32341 | Pinion |
| 708-2H-32320 | Bushing | 708-2H-32330 | Impeller |
| 01010-61220 | Bolt | 708-2H-32350 | Washer |
| 708-2H-32360 | Shaft | 708-2H-32370 | Cover |
| 07000-A2105 | O-ring | 708-2H-05120 | Shim Kit |
| 01010-81235 | Bolt | 01643-31232 | Washer |
| 708-2L-35311 | Sleeve | 708-2L-24680 | Seal |
| 708-2G-15412 | Spool | 708-2L-28540 | Piston |
| 708-2L-35360 | Sleeve | 708-2L-35331 | Seat |
| 708-2L-35410 | Spring | 708-2L-35341 | Seat |
| 708-2L-35351 | Plug | 07000-B1009 | O-ring |
| 07001-01009 | Ring, Back-up | 01583-11408 | Nut |
| 07002-62434 | O-ring | 702-21-57600 | Valve, Pilot |
| 01252-60635 | Bolt, Hexagon Socket Head | 20Y-62-22790 | Band, Red |
| 702-21-57500 | Valve, Pilot | 702-16-55260 | Bolt |
| 20Y-62-22830 | Band, White | 702-21-55400 | Valve Assembly |
| 702-21-55920 | Plug | 702-21-55930 | Piston |
| 702-21-55940 | Spring | 702-21-55951 | Block |
| 07002-12034 | O-ring | 07000-11008 | O-ring |
| 722-12-18240 | O-ring | 01252-60530 | Bolt, Hexagon Socket Head |
| 708-2H-15531 | Plug | 07000-B1008 | O-ring |
| 07001-01008 | Ring, Back-up | 07002-61423 | O-ring |
| 01643-51232 | Washer | 01010-81220 | Bolt |
| 08193-21012 | Clip | 708-2H-12430 | Bearing |
| 07000-A5190 | O-ring | 04020-01434 | Pin, Dowel |
| 708-1L-29340 | Orifice | 01010-61860 | Bolt |
| 01643-31845 | Washer | 708-2L-25480 | Filter |
| 708-8E-16150 | Plug | 07002-61023 | O-ring |
| 708-2H-32110 | Shaft | 708-1H-22150 | Bearing |
| 708-17-05010 | Washer Kit | 708-17-12780 | Ring, Snap, Snap |
| 708-2H-22570 | Seal, Oil | 708-27-22811 | Seal, Oil |
| 708-2H-22160 | Spacer | 04065-08225 | Ring, Snap |
| 708-2H-04750 | Cylinder Block Assembly | 708-18-13230 | Pin |
| 04065-05820 | Ring, Snap | 708-2H-33140 | Seat |
| 708-2H-33150 | Spring | 708-2H-23141 | Seat |
| 708-2H-23350 | Guide, Retainer, Retainer | 708-2H-23360 | Pin |
| 708-2H-33343 | Retainer, Shoe, Shoe | 708-2H-33311 | Piston Subassembly |
| 708-2H-04690 | Cradle Subassembly | 04020-01434 | Pin, Dowel |
| 07000-B1009 | O-ring | 01252-61235 | Bolt, Hexagon Socket Head |
| 708-2H-34150 | Slider | 708-2H-03411 | Valve Assembly, Pc |
| 708-2H-03022 | Piston Assembly, Servo | 708-2G-15320 | Seal |
| 708-2H-15310 | Plug | 708-2L-35760 | Ball |
| 708-2L-35770 | Plug | 708-2L-35690 | Seal |
| 708-2L-35170 | Pin | 708-3M-15670 | Spool |
| 708-2G-15290 | Retainer | 708-2G-15140 | Seat |
| 708-2H-15330 | Spring | 708-2H-15320 | Spring |
| 708-2G-15151 | Seat | 708-2H-15340 | Spring |
| 708-2G-14340 | Screw | 07000-B3038 | O-ring |
| 708-2G-15230 | Ring, Back-up | 708-2G-15260 | Seal |
| 708-2G-15240 | Plug | 07000-B2012 | O-ring |
| 07000-B2050 | O-ring | 708-2G-15310 | Ring, Back-up |
| 708-2L-44161 | Cover | 01580-10806 | Nut |
| 708-2L-35540 | Nut | 708-2G-15330 | Ring, Wear |
| 01252-61645 | Bolt, Hexagon Socket Head | 708-2H-00450 | Pump Assembly |
| 708-2H-01450 | Pump Subassembly | 708-2H-03510 | Cover Assembly |
| 708-2G-14310 | Screw | 07000-B3038 | O-ring |
| 708-2G-15230 | Ring, Back-up | 708-2L-35540 | Nut |
| 708-2L-44130 | Cover | 07000-B2050 | O-ring |
| 708-2G-15310 | Ring, Back-up | 01252-61645 | Bolt, Hexagon Socket Head |
| 07044-12412 | Plug | 07002-62434 | O-ring |
| 20B-27-11210 | Bleeder | 07000-B2012 | O-ring |
| 04530-11222 | Bolt, Eye | 708-8E-16150 | Plug |
| 07002-61023 | O-ring | 07040-12414 | Plug |
| 708-2H-32210 | Shaft | 708-1H-22150 | Bearing |
| 708-17-05010 | Washer Kit | 708-17-12780 | Ring, Snap, Snap |
| 708-2H-04760 | Block Assembly,Rear | 708-18-13230 | Pin |
| 04065-05820 | Ring, Snap | 708-2H-33140 | Seat |
| 708-2H-33150 | Spring | 708-2H-23141 | Seat |
| 708-2H-23350 | Guide, Retainer | 708-2H-23360 | Pin |
| 708-2H-33343 | Retainer, Shoe | 708-2H-33311 | Piston Subassembly |
| 708-2H-04690 | Cradle Subassembly | 04020-01434 | Pin, Dowel |
| 07000-B1009 | O-ring | 01252-61235 | Bolt, Hexagon Socket Head |
| 708-2H-32130 | Coupling | 708-2H-12420 | Ring |
5. Related models:
| PC400-7 | PC400-7-M1 | PC450LC-7-M1 | PC450LC-7 | PC450-7-M1 |
| PC450-7 | PC400LC-7-M1 | PC400LC-7 | PC450-7K | PC450LC-7K |
| PC400LC-7L | PC400-7(-50) | PC220LL-8 | PC5500-6E | PC300LC-5LC |
| D61PXI-23 | D20A-3 | D475A-3 | PC05-5 | PC800LC-8R1 |
| PC78US-5 | D20A-6 | PC400LC-5 | PC850-8E0 | PC300HD-7L |
| PC120-5S | PC380UU-1 | D40AF-1A | PC228USLC-8 | PC120LC-6 |
| D39PX-22 | PC60-6C | PC350-6 | PC158US-2 | PC220LL-7L |
| D40PF-3A | PC600LC-8K | D61EX-12A | PC20MR-2 | PC09FR-1 |
| DRP060-4A | D670E | PC118MR-8 | PC07-2 | PC400LC-6LC |
| D21P-3 | D50A-17 | PC600LC-6A-KJ | PC340LCD-7K | PC200CA-6 |
| D21P-7T | PC10-6 | PC15-2A | PC12R-8 | PC160-6K |
| PC600LC-8 | PC200-6Z | PC350LC-7 | D40A-1 | PC600-6KJ-KU |
| PC09-1 | PC450LC-6K | PC60L-6 | PC70-6 | PW170ES-6K |
